EM-5P Portable UV Flue Gas Analyzer is mainly composed by monitoring unit of gaseous pollutants (SO2, NOX, CO, CO2), monitoring unit of flue gas parameters (e.g. oxygen content), data collection & processing unit. The structure consists of flue gas sampler, transmission pipeline, flue gas pre-processor and analyzer. The product is equipped with Android touch screen, large storage capacity, multi-port output and printer for real-time monitoring data, etc.
Adopt Stoichiometric Algorithm, low detection limit and small temperature drift.
NOX content can be directly obtained by measuring NO and NO2.
without NO2→NO converter.
Full UV spectrum measurement, without cross interference.
Electronic scanning of full spectrum, no optical moving parts.
Low requirements for measured gas, able to applied in dust and high humidity working condition.
Applied in exhaust emission monitoring and process control in coal-fired power plant, garbage power plant, cement plant, glass plant, lime factory, ceramics factory, sintering process, coke oven, desulfurization technology, denitration technology, etc.
Analyzer model: normal temp type: condensation & water removal/.
high temp type: full-course high temperature.
Measurement technology: UV-DOAS (SO2, NO, NO2), electrochemistry (O2), infrared/laser (CO), infrared/laser TDLAS,(CO2)
Range: 0~50~1500mg/m3 (SO2, NO, NO2), 0~25% (O2), 0~500~10000ppm (CO), 0~65% (CO2)
Indication error: ≤2%F.S..
Zero drift: ≤2%F.S./24h.
Span drift: ≤2%F.S./24h.
Response time: ≤90s (T90)
Preheating time: normal temp type:10 min/high temp type: 40min
Power: 220VAC±22V, normal temp type: 50W/high temp type: 350W
Working temperature: 5℃~45℃
Working humidity: 0～85%RH
