EmailSCEM-5 Continuous Emission Monitoring System (Ultra-low Hot-wet) is developed for ultra-low emission monitoring in key area, composed by dust monitoring subsystem, gaseous pollutant monitoring subsystem, flue gas parameter monitoring subsystem, and system control & data acquisition & processing subsystem. It can monitor SO2, NOX, O2, dust, temperature, pressure, velocity, etc. Other parameters can be extended as required for special occasions, such as HCl, HF, CO, CO2, humidity, etc. The lower limit can reach 1mg/m3, meeting technical requirements of ultra-low emission monitoring occasions.
Features
Lower limit of measurement can reach 1mg/m3.
Simple structure and high reliability.
Self-developed core modules and algorithms.
Compact structure, convenient for transport and installation.
Realize full-course calibration.
Application
Applied in exhaust emission monitoring and process control in coal-fired power plant, garbage power plant, cement plant, glass plant, lime factory, ceramics factory, sintering process, coke oven, desulfurization technology, denitration technology, etc.
Specifications
SO2, NO: 0~50~100ppm (lower range can be customized).
NO2: 0~100~200ppm (lower range can be customized) .
O2: 0~25%, humidity: 0~40%.
Dust: 0~20mg/m3, 0~50mg/m3.
Velocity: 0~40m/s (customizable).
Temperature: 0~300℃ (customizable).
Pressure: -10kPa~10kPa (customizable).
Dimension: 800mmx600mmx1800mm.
Tracing temperature: 120℃~180℃.
IP grade: cabinet IP42, others IP65.
Power supply: (220±15%)VAC, 5000W.
Working temperature: -20℃~50℃.
Working humidity: 0~95%RH (non-condensing).
Compressed air: (0.4~0.8)MPa, 0.25m3/min, clean, oil-free & water-free.
